Custom SRP 5.0.0

Skybox Pass

Let's begin with SkyboxPass, which is one of the simplest passes. To turn it into an unsafe pass we have to replace the invocation of AddRenderPass in Record with AddUnsafePass.

			using RenderGraphBuilder builder = renderGraph.AddUnsafePass(
				sampler.name, out SkyboxPass pass, sampler);

Now we no longer get a generic RenderGraphBuilder, but instead one specific for unsafe passes. The method's return type isn't a specific class but an interface, in this case IUnsafeRenderGraphBuilder. It might be inconvenient to explicitly name this type, but I do so for clarity's sake instead of using var.

			using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
				sampler.name, out SkyboxPass pass, sampler);

The new builder forces us to change our approach a little. We used to invoke create methods on the render graph, pass their return value to the builder's usage method, and assign the result to that to the pass data. This no longer works because the builder's usage methods no longer return their argument. So we have to turn such code into two separate statements.

			//pass.list = builder.UseRendererList(
				//renderGraph.CreateSkyboxRendererList(camera));
			pass.list = renderGraph.CreateSkyboxRendererList(camera);
			builder.UseRendererList(pass.list);

Also, the read, write, and readwrite methods have been consolidated into a single use method. So we have to replace ReadWriteTexture and ReadTexture with UseTexture.

			//builder.ReadWriteTexture(textures.colorAttachment);
			//builder.ReadTexture(textures.depthAttachment);
			builder.UseTexture(textures.colorAttachment);
			builder.UseTexture(textures.depthAttachment);

By default usage is read-only and other access types can be specified by adding an AccessFlags argument. So for the color attachment we add AccessFlags.ReadWrite.

			builder.UseTexture(textures.colorAttachment, AccessFlags.ReadWrite);

Our Render method will now be passed a more restricted UnsafeGraphContext.

	void Render(UnsafeGraphContext context) { … }

A big change of this new approach is that we no longer have to execute and clear the command buffer ourselves, which simplifies the code. The only thing left for us to do is add the command for drawing the renderer list.

	void Render(UnsafeGraphContext context)
	{
		context.cmd.DrawRendererList(list);
		//context.renderContext.ExecuteCommandBuffer(context.cmd);
		//context.cmd.Clear();
	}

In fact, we can no longer execute command buffers ourselves at all. This is now entirely managed by the render graph.

Geometry Pass

Let's convert GeometryPass next. Its Render method requires the same changes, making it exactly the same as for the skybox, just a single DrawRendererList invocation. So I won't explicitly show it. Adjust Record similarly as well. If we initially ignore the buffer usages, it's just more of the same.

		using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
			sampler.name, out GeometryPass pass, sampler);

		//pass.list = builder.UseRendererList(renderGraph.CreateRendererList(
		pass.list = renderGraph.CreateRendererList(
			new RendererListDesc(shaderTagIDs, cullingResults, camera)
			{
				…
			}); //);

		builder.UseRendererList(pass.list);
		builder.UseTexture(textures.depthAttachment, AccessFlags.ReadWrite);
		builder.UseTexture(textures.colorAttachment, AccessFlags.ReadWrite);

		if (!opaque)
		{
			if (textures.colorCopy.IsValid())
			{
				builder.UseTexture(textures.colorCopy);
			}
			if (textures.depthCopy.IsValid())
			{
				builder.UseTexture(textures.depthCopy);
			}
		}

		…
		builder.UseTexture(lightData.shadowResources.directionalAtlas);
		builder.UseTexture(lightData.shadowResources.otherAtlas);

The usage of the buffers requires the similar changes as for textures. Although the UseBuffer method does return the buffer, this is not intended and it will become a void method in the future to match the other usage methods, so let's treat it as such.

		builder.UseBuffer(lightData.directionalLightDataBuffer);
		builder.UseBuffer(lightData.otherLightDataBuffer);
		builder.UseBuffer(lightData.tilesBuffer);
		builder.UseTexture(lightData.shadowResources.directionalAtlas);
		builder.UseTexture(lightData.shadowResources.otherAtlas);
		builder.UseBuffer(
			lightData.shadowResources.directionalShadowCascadesBuffer);
		builder.UseBuffer(
			lightData.shadowResources.directionalShadowMatricesBuffer);
		builder.UseBuffer(lightData.shadowResources.otherShadowDataBuffer);

Unsupported Shaders Pass

Make the same changes to UnsupportedShadersPass. While we're at it, add texture usage indicators for it as well, which we had omitted until now. I only show the changes for that.

	public static void Record(
		RenderGraph renderGraph,
		Camera camera,
		CullingResults cullingResults,
		in CameraRendererTextures textures)
	{
		…
		builder.UseRendererList(pass.list);
		builder.UseTexture(textures.colorAttachment, AccessFlags.ReadWrite);
		builder.UseTexture(textures.depthAttachment, AccessFlags.ReadWrite);

		…
	}

This requires us to pass the textures when recording it in CameraRenderer.Render.

			UnsupportedShadersPass.Record(
				renderGraph, camera, cullingResults, textures);

Debug Pass

Upgrade DebugPass in the same way. As the rendering work is done by CameraDebugger.Render We also have to make changes to that method, changing its context parameter type. Also, each context now has its own buffer type, in this case UnsafeCommandBuffer. This limits what kind of commands we can issue, though the unsafe context is the least restricted.

	public static void Render(UnsafeGraphContext context)
	{
		UnsafeCommandBuffer buffer = context.cmd;
		buffer.SetGlobalFloat(opacityID, opacity);
		buffer.DrawProcedural(
			Matrix4x4.identity, material, 0, MeshTopology.Triangles, 3);
		//context.renderContext.ExecuteCommandBuffer(buffer);
		//buffer.Clear();
	}

Setup Pass

Adapt SetupPass.Record as expected. In this case we use AccessFlags.WriteAll for the attachments. This indicates that we're going to fully write the contents of the textures and don't need their original data to be loaded.

		using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
			sampler.name, out SetupPass pass, sampler);
		…

		TextureHandle colorAttachment = pass.colorAttachment =
			//builder.WriteTexture(renderGraph.CreateTexture(desc));
			renderGraph.CreateTexture(desc);
		builder.UseTexture(colorAttachment, AccessFlags.WriteAll);
		…
		TextureHandle depthAttachment = pass.depthAttachment =
			//builder.WriteTexture(renderGraph.CreateTexture(desc));
			renderGraph.CreateTexture(desc);
		builder.UseTexture(depthAttachment, AccessFlags.WriteAll);

The unsafe context doesn't expose the render context, so we can no longer invoke SetupCameraProperties on it in Render. We now invoke it on the command buffer instead.

	void Render(UnsafeGraphContext context)
	{
		//context.renderContext.SetupCameraProperties(camera);
		UnsafeCommandBuffer cmd = context.cmd;
		cmd.SetupCameraProperties(camera);
		…
		//context.renderContext.ExecuteCommandBuffer(cmd);
		//cmd.Clear();
	}

Post FX Pass

Moving on to the post-FX stack, the changes to PostFXPass.Record are as expected.

		using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
			finalSampler.name, out PostFXPass pass, finalSampler);
		pass.keepAlpha = keepAlpha;
		pass.stack = stack;
		//pass.colorSource = builder.ReadTexture(colorSource);
		pass.colorSource = colorSource;
		builder.UseTexture(colorSource);
		builder.UseTexture(colorLUT);

We're now passing an unsafe command buffer around and from now on we're going to work with TextureHandle exclusively when referencing textures, replacing RenderTargetIdentifier.

	void ConfigureFXAA(UnsafeCommandBuffer buffer) { … }

	void Render(UnsafeGraphContext context)
	{
		UnsafeCommandBuffer buffer = context.cmd;
		buffer.SetGlobalFloat(finalSrcBlendId, 1f);
		buffer.SetGlobalFloat(finalDstBlendId, 0f);

		TextureHandle finalSource;
		…
		//context.renderContext.ExecuteCommandBuffer(buffer);
		//buffer.Clear();
	}

Adjust PostFXStack to also work with UnsafeCommandBuffer and TextureHandle. This requires us to import the UnityEngine.Rendering.RenderGraphModule namespace.

Update ColorLUTPass to match. As we're fully generating the LUT texture use AccessFlags.WriteAll for it in Record.

		using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
			sampler.name, out ColorLUTPass pass, sampler);
		…
		//pass.colorLUT = builder.WriteTexture(renderGraph.CreateTexture(desc));
		pass.colorLUT = renderGraph.CreateTexture(desc);
		builder.UseTexture(pass.colorLUT, AccessFlags.WriteAll);

The same goes for BloomPass, using AccessFlags.WriteAll for the bloomResult texture.

Lighting Pass

LightingPass needs a bit more work. We Begin with Record, making the usual changes.

		using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
			sampler.name, out LightingPass pass, sampler);
		pass.Setup(cullingResults, attachmentSize,
			forwardPlusSettings, shadowSettings, renderingLayerMask);

		//pass.directionalLightDataBuffer = builder.WriteBuffer(
		pass.directionalLightDataBuffer = renderGraph.CreateBuffer(
			new BufferDesc(
				maxDirectionalLightCount, DirectionalLightData.stride)
			{
				name = "Directional Light Data"
			}); //);
		builder.UseBuffer(
			pass.directionalLightDataBuffer, AccessFlags.WriteAll);
		//pass.otherLightDataBuffer = builder.WriteBuffer(
		pass.otherLightDataBuffer = renderGraph.CreateBuffer(new BufferDesc(
			maxOtherLightCount, OtherLightData.stride)
		{
			name = "Other Light Data"
		}); //);
		builder.UseBuffer(pass.otherLightDataBuffer, AccessFlags.WriteAll);
		//pass.tilesBuffer = builder.WriteBuffer(
		pass.tilesBuffer = renderGraph.CreateBuffer(new BufferDesc(
			pass.TileCount * pass.maxTileDataSize, 4
		)
		{
			name = "Forward+ Tiles"
		}); //);
		builder.UseBuffer(pass.tilesBuffer, AccessFlags.WriteAll);

Then adapt Render as expected. From now on we'll pass the command buffer to shadows.Render directly. Also, we should no longer immediately dispose the tile data. We shouldn't do this because we do not control when the buffer gets executed and we have to ensure that the tile data remains valid until after it has been copied.

	void Render(UnsafeGraphContext context)
	{
		UnsafeCommandBuffer buffer = context.cmd;
		…

		shadows.Render(context.cmd);

		…
		// context.renderContext.ExecuteCommandBuffer(buffer);
		// buffer.Clear();
		lightBounds.Dispose();
		// tileData.Dispose();
	}

To keep this working we'll keep the tile data until we're sure that it is no longer needed. First, we make its field static.

	static NativeArray<int> tileData;

Second, in SetupLights we no longer create a temporary array. We instead check whether the array doesn't exist yet or if its length is incorrect. If so, dispose the array if it exists, then create a new persistent array with the correct length.

		//tileData = new NativeArray<int>(
			//TileCount * tileDataSize, Allocator.TempJob);
		int tileDataLength = TileCount * tileDataSize;
		if (!tileData.IsCreated || tileData.Length != tileDataLength)
		{
			if (tileData.IsCreated)
			{
				tileData.Dispose();
			}
			tileData = new(tileDataLength, Allocator.Persistent,
				NativeArrayOptions.UninitializedMemory);
		}

This does mean that the tile data would stick around after the last frame gets rendered, so we have to clean it up. Add a public static Cleanup method that disposes it.

	public static void Cleanup() => tileData.Dispose();

Invoke it in CameraRenderer.Dispose.

	public void Dispose()
	{
		CoreUtils.Destroy(material);
		CameraDebugger.Cleanup();
		LightingPass.Cleanup();
	}

Next, adjust Shadows so it works with UnsafeCommandBuffer and IUnsafeRenderGraphBuilder. Its Render method now directly accepts the command buffer, skipping the context.

	public void Render(UnsafeCommandBuffer buffer)
	{
		// buffer = context.cmd;
		this.buffer = buffer;

		…
		//context.renderContext.ExecuteCommandBuffer(buffer);
		//buffer.Clear();
	}

Change the usage of renderer lists and textures as needed. This requires a little more verbose code in GetResources because we can no longer do everything in a single statement.

		//directionalAtlas = shadowedDirLightCount > 0 ?
			//builder.WriteTexture(renderGraph.CreateTexture(desc)) :
			//renderGraph.defaultResources.defaultShadowTexture;
		if (shadowedDirLightCount > 0)
		{
			directionalAtlas = renderGraph.CreateTexture(desc);
			builder.UseTexture(directionalAtlas, AccessFlags.WriteAll);
		}
		else
		{
			directionalAtlas =
				renderGraph.defaultResources.defaultShadowTexture;
		}

		…
		//otherAtlas = shadowedOtherLightCount > 0 ?
			//builder.WriteTexture(renderGraph.CreateTexture(desc)) :
			//renderGraph.defaultResources.defaultShadowTexture;
		if (shadowedOtherLightCount > 0)
		{
			otherAtlas = renderGraph.CreateTexture(desc);
			builder.UseTexture(otherAtlas, AccessFlags.WriteAll);
		}
		else
		{
			otherAtlas = renderGraph.defaultResources.defaultShadowTexture;
		}

Copy Attachments Pass

Change CopyAttachmentsPass as usual. In CameraRendererCopier, change its method parameters to UnsafeCommandBuffer and TextureHandle. This will reveal to use that we can no longer use CopyTexture. From now on we have to rely on the CopyByDrawing approach. While this might be less than ideal, we could optimize this a bit but will leave that for the future. It does simplify our copier.

Remove copyTextureSupported, RequiresRenderTargetResetAfterCopy, and the Copy method. Then rename CopyByDrawing to Copy and adjust its parameter types.

	//static readonly bool copyTextureSupported =
		//SystemInfo.copyTextureSupport > CopyTextureSupport.None;

	//public static bool RequiresRenderTargetResetAfterCopy =>
		//!copyTextureSupported;

	…

		//public readonly void Copy(…) { … }

	//public readonly void CopyByDrawing(
	public readonly void Copy(
		UnsafeCommandBuffer buffer,
		TextureHandle from,
		TextureHandle to,
		bool isDepth)
	{ … }

From now on we have to ensure that the source and destination blend shader properties are always set correctly in Copy, otherwise drawing will fail.

		buffer.SetGlobalFloat(srcBlendID, 1f);
		buffer.SetGlobalFloat(dstBlendID, 0f);
		buffer.SetGlobalTexture(sourceTextureID, from);

And we now have to always reset the render target in CopyAttachmentsPass.Render

		//if (CameraRendererCopier.RequiresRenderTargetResetAfterCopy)
		//{
		buffer.SetRenderTarget(
			colorAttachment,
			RenderBufferLoadAction.Load, RenderBufferStoreAction.Store,
			depthAttachment,
			RenderBufferLoadAction.Load, RenderBufferStoreAction.Store
		);
		//}

Gizmos Pass

Next up is GizmosPass. From now on we also have to use renderer lists for this pass. This requires us to add fields for the renderer lists. Also, we now have to use a texture handle for the camera target, so add a field for it.

	TextureHandle depthAttachment, cameraTarget;

	RendererListHandle preList, postList;

Make Record set everything up using the new approach. We need to read from the depth attachment and can create the gizmos renderer lists via RenderGraph.CreateGizmoRendererList. We can get a texture handle for the camera target via RenderGraph.ImportBackbuffer(BuiltinRenderTextureType.CameraTarget). Also, like for the skybox pass we have to disable pass culling because these renderer lists are considered empty for pass culling.

			using IUnsafeRenderGraphBuilder builder = renderGraph.AddUnsafePass(
				sampler.name, out GizmosPass pass, sampler);
			pass.copier = copier;
			//pass.depthAttachment = builder.ReadTexture(
				textures.depthAttachment);
			pass.depthAttachment = textures.depthAttachment;
			builder.UseTexture(pass.depthAttachment);
			pass.preList = renderGraph.CreateGizmoRendererList(
				copier.Camera€, GizmoSubset.PreImageEffects);
			builder.UseRendererList(pass.preList);
			pass.postList = renderGraph.CreateGizmoRendererList(
				copier.Camera€, GizmoSubset.PostImageEffects);
			builder.UseRendererList(pass.postList);
			pass.cameraTarget = renderGraph.ImportBackbuffer(
				BuiltinRenderTextureType.CameraTarget);
			builder.UseTexture(pass.cameraTarget, AccessFlags.WriteAll);
			builder.AllowPassCulling(false);
			builder.SetRenderFunc<GizmosPass>(
				static (pass, context) => pass.Render(context));

In Render we now have to perform the depth copy and draw the renderer lists.

	void Render(UnsafeGraphContext context)
	{
		UnsafeCommandBuffer buffer = context.cmd;
		//ScriptableRenderContext renderContext = context.renderContext;
		copier.Copy(buffer, depthAttachment, cameraTarget, true);
		//renderContext.ExecuteCommandBuffer(buffer);
		//buffer.Clear();
		//renderContext.DrawGizmos(copier.Camera, GizmoSubset.PreImageEffects);
		//renderContext.DrawGizmos(copier.Camera, GizmoSubset.PostImageEffects);
		buffer.DrawRendererList(preList);
		buffer.DrawRendererList(postList);
	}

Final Pass

The last pass to change is FinalPass. This is another straightforward upgrade. The parameter types of CameraRendererCopier.CopyToCameraTarget also have to changed. To keep things simple we'll still rely on BuiltinRenderTextureType.CameraTarget in that method.

We have now migrated our render pipeline to the newer Render Graph API so it won't fail when the old methods get removed. In the future we will further specialize our passes so rendering can potentially become more efficient.
